Product Description
BULLET12A — Bullet Flood 12W/9W/6W Field Adjustable LED CCT Selectable 3000K/4000K/5000K with Hood & Lens Bronze from RAB Lighting is a compact and versatile LED floodlight engineered for high-performance outdoor illumination. Featuring field-adjustable wattage and selectable color temperatures, this durable bronze fixture provides reliable, energy-efficient lighting for a wide range of landscape, security, and architectural applications.
Product Summary
- Wattage: 12W / 9W / 6W selectable
- Lumens: 636 – 1324 lm
- Color Temperature: 3000K / 4000K / 5000K selectable
- Voltage: 120V
- CRI: 82–85 CRI
- Beam Spread: NEMA 6H x 6V
- Rating: IP65 Wet Location Rated
- Lifespan: 100000 hours
- Finish: Bronze
- Warranty: 5-Year Limited
- Shipping: Free shipping on orders over $250
Product Benefits
- Field-adjustable wattage and selectable CCT provide flexibility for various lighting needs and project requirements.
- Durable die-cast aluminum construction ensures long-lasting performance in harsh outdoor environments.
- High lumen output with efficient LED technology reduces energy consumption while maintaining brightness.
- Extended 100000-hour lifespan minimizes maintenance and replacement costs.
Key Features
- Adjustable Wattage: Select between 12W, 9W, or 6W for optimal light levels.
- CCT Selectable: Choose 3000K, 4000K, or 5000K color temperature.
- TRIAC Dimming: Compatible with dimmers down to 10%.
- IP65 Rated: Protection against dust and water for outdoor use.
- Robust Construction: Die-cast aluminum housing with glass lens.
- Wide Temperature Range: Operates from -40°F to 104°F.
- Efficient LEDs: Up to 116.4 lm/W efficacy.
- Secure Mounting: Heavy-duty arm with O-ring seal and stainless steel screws.
Specifications
Technical Specifications
| Wattage | 12W / 9W / 6W |
| Voltage | 120V |
| Input Watts | 5.7W – 12.3W |
| Current | 0.10A |
| Power Factor | 99% |
| THD | 14.53% |
| Surge Protection | 1kV |
Performance Specifications
| Lumens | 636 – 1324 lm |
| Efficacy | 100.2 – 116.4 lm/W |
| CRI | 82 – 85 |
| CCT | 3000K / 4000K / 5000K |
| Lifespan | 100000 hours |
| Beam Spread | NEMA 6H x 6V |
Physical & Construction
| Housing | Die-cast aluminum |
| Lens | Glass |
| Reflector | PET |
| Finish | Bronze |
| Weight | 0.8 lbs |
| Operating Temp | -40°F to 104°F |
Compliance & Safety
| Listings | UL Listed for wet locations |
| IP Rating | IP65 |
| Testing | IESNA LM-79 & LM-80 |
| Compliance | Trade Agreements Act Compliant |
| Environmental | RoHS compliant, mercury & UV free |
Applications
- Landscape and garden lighting
- Security and perimeter illumination
- Architectural accent lighting
- Sign and display lighting
- Residential and commercial outdoor projects
Installation Tips
- Securely mount using the included heavy-duty arm and hardware.
- Ensure the O-ring seal is properly seated to maintain IP65 protection.
- Select wattage and color temperature before final installation.
- Install within rated temperature range for optimal longevity.
- Use compatible TRIAC dimmers for best dimming performance.
FAQ
Is the wattage adjustable?
Yes, you can select between 12W, 9W, and 6W depending on your lighting needs.
What color temperatures are available?
The fixture allows selection between 3000K, 4000K, and 5000K.
Can this floodlight be dimmed?
Yes, it supports TRIAC dimming down to 10%.
Is this light suitable for outdoor use?
Yes, it is UL listed for wet locations and rated IP65 for protection against water and dust.
What is the expected lifespan?
The LED is rated for up to 100000 hours of operation.
What is the beam spread?
The light features a NEMA 6H x 6V beam spread for focused illumination.
What materials is the fixture made from?
It features a die-cast aluminum housing with a glass lens and PET reflector.
Can it operate in cold weather?
Yes, it can start and operate in temperatures as low as -40°F.
