Product Description
STL360W Outdoor Sensors Stealth 360 Sensor 1000W 120V White by RAB Lighting is a versatile outdoor sensor offering exceptional full coverage detection. With 180° forward and 360° downward detection, this sensor is ideal for comprehensive perimeter security and motion-activated lighting control.
Key Features:
- Enhanced detection: 180° forward and 360° downward coverage.
- Handles up to 1000W incandescent load at 120 volts.
- Evening Timer provides continuous lighting from 1 to 8 hours after dusk.
- Advanced detection logic minimizes false triggers.
- Adjustable sensitivity from 30% to 100%.
- Photoelectric control for daylight deactivation and custom operation.
- Surge protection up to 6000 volts for durability.
- Pre-wired and assembled on the CU4 EZ Plate for hassle-free installation.
- 10-year sensor warranty for peace of mind.
Specifications:
- Wattage: 1000W (incandescent)
- Voltage: 120V AC
- Power Consumption: 1W
- Detection Range: 180° forward, 360° downward
- Time Adjustment: 5 seconds to 12 minutes
- Weight: 1.5 lbs
- Material: Precision die-cast aluminum
- Compliance: UL Listed, suitable for wet locations
Installation Tips:
- Mount 6–10 feet high for optimal detection range.
- Aim the sensor away from reflective surfaces and heat sources.
- Use the CU4 EZ Plate for a secure and stable installation.
- Adjust the Evening Timer and sensitivity settings for desired performance.
- Follow the installation guide for step-by-step setup instructions.
Frequently Asked Questions:
Q: What is the maximum wattage this sensor can handle?
A: It can handle up to 1000W incandescent load at 120V.
Q: How does the Evening Timer feature work?
A: The Evening Timer allows the sensor to keep lights on for 1 to 8 hours after dusk, switching to motion detection mode afterward.
Q: Can this sensor operate during the day?
A: Yes, the photoelectric control supports 24-hour operation or daylight deactivation.
Q: How do the scanning LEDs function?
A: The scanning LEDs indicate the sensor's mode of operation and serve as a security deterrent.
Q: Is this sensor compatible with LED fixtures?
A: It supports LED fixtures with specific ballast capacities (250VA standard or 300VA electronic).
Q: Is there a warranty for this product?
A: Yes, it comes with a 10-year sensor warranty.
