Product Description
RAB GLED52Y Garage Lights 5883 Lumens GLED 52W 3000K Bronze is a high-performance LED garage lighting solution designed for durability, efficiency, and optimal light distribution in parking structures and covered ceiling applications. Engineered by RAB Lighting, this fixture delivers powerful illumination while significantly reducing energy consumption compared to traditional metal halide systems.
Product Summary
- Wattage: 52W
- Lumens: 5883 lm
- Color Temperature: 3000K
- Voltage: 120-277V
- Efficacy: 109.6 lm/W
- CRI: 72
- Lifespan: 100000 hours
- Finish: Bronze
- Mounting: Ceiling mount
- Rating: Wet location, DLC Listed, UL Listed
- Warranty: 5 years
- Shipping: Free shipping on orders over $250
Product Benefits
- Reduces energy consumption by replacing 175W metal halide fixtures with efficient 52W LED technology.
- Delivers consistent, high-output illumination ideal for parking garages and covered outdoor environments.
- Long 100000-hour lifespan minimizes maintenance and replacement costs.
- Wide voltage compatibility (120-277V) supports flexible installation across various electrical systems.
Key Features
- High Lumen Output: 5883 lumens for bright, uniform coverage.
- Energy Efficient: 109.6 lm/W efficacy for maximum performance.
- Durable Construction: Precision die-cast aluminum housing with bronze finish.
- Advanced Optics: Prismatic polycarbonate lens with 97% reflective optics.
- 0-10V Dimming: Dimmable down to 10% with compatible control systems.
- Cold Weather Rated: Operates in temperatures as low as -40°C.
- Surge Protection: Built-in 6kV surge protection for reliability.
- Color Consistency: 3-step MacAdam ellipse binning ensures uniform light output.
Specifications
Technical Specifications
| Wattage | 52W |
| Input Watts | 53.7W |
| Voltage | 120-277V |
| Frequency | 50/60 Hz |
| Power Factor | 99.9% (120V), 96.5% (277V) |
| THD | 3.2% (120V), 6.08% (277V) |
Performance Specifications
| Lumens | 5883 lm |
| Efficacy | 109.6 lm/W |
| Color Temperature | 3000K |
| CRI | 72 |
| Lifespan (L70) | 100000 hours |
| BUG Rating | B2 U3 G1 |
Physical Specifications
| Finish | Bronze |
| Housing | Die-cast aluminum |
| Lens | Prismatic polycarbonate |
| Mounting | Ceiling mount with hanging plate hooks |
| Weight | 17.4 lbs |
Compliance & Safety
| UL Listed | Yes, suitable for wet locations (covered ceiling mount) |
| DLC Listed | Yes (DLC 5.1 Qualified) |
| RoHS | Compliant |
| Surge Protection | 6kV |
Applications
- Parking garages and parking structures
- Covered walkways and canopies
- Commercial and industrial facilities
- Warehouses and storage areas
- Transit stations and loading docks
Installation Tips
- Ensure power is turned off before installation or maintenance.
- Mount securely to a junction box using the provided ceiling plate and hooks.
- Use weatherproof silicone sealant to maintain proper sealing and protection.
- Follow proper wiring procedures for both standard and 0-10V dimming configurations.
- Avoid pinching wires and ensure all connections comply with local electrical codes.
FAQ
What is the lumen output of this fixture?
This fixture delivers 5883 lumens, providing bright and uniform illumination.
Can this replace metal halide fixtures?
Yes, it is designed to replace up to 175W metal halide fixtures while using significantly less energy.
Is this fixture dimmable?
Yes, it supports 0-10V dimming and can dim down to 10% with compatible controls.
What voltage does it operate on?
The fixture operates on a universal voltage range of 120-277V.
Is it suitable for outdoor use?
Yes, it is UL listed for wet locations when used in covered ceiling mount applications.
What is the expected lifespan?
The LED lifespan is rated at 100000 hours based on industry testing standards.
Can it operate in cold environments?
Yes, it can start and operate in temperatures as low as -40°C.
What type of mounting is required?
It is designed for ceiling mounting using a junction box and included hanging plate system.
