Product Description
The CDLED2W-20W-WW927-K is a premium 2-inch LED wall-mounted cylinder fixture engineered for direct and indirect architectural illumination. Delivering 1144 lumens with warm 2700K color temperature and high color rendering, this compact fixture provides modern up/down lighting performance ideal for commercial and residential wall applications.
Product Summary
- Model: CDLED2W-20W-WW927-K
- Fixture Type: LED Wall Mount Cylinder
- Lighting Distribution: Direct / Indirect
- Wattage: 20W
- Lumens: 1144 lm
- Color Temperature: 2700K Warm White
- Cylinder Size: 2 Inches
- Dimming: 0-10V Dimmable
- Voltage: 120V-277V
- Location Rating: Wet Location
Benefits
- Provides elegant up/down architectural lighting effects
- Compact 2-inch profile for clean modern aesthetics
- Warm 2700K illumination creates comfortable environments
- Suitable for indoor and outdoor wet location installations
- Universal voltage driver supports commercial applications
- 0-10V dimming allows smooth lighting control integration
Key Features
- Direct/Indirect Lighting: Delivers balanced upward and downward illumination.
- 1144 Lumens Output: Efficient LED performance for architectural wall lighting.
- Warm White 2700K: Comfortable residential and hospitality lighting tone.
- 0-10V Dimming: Compatible with modern lighting control systems.
- Wet Location Rated: Suitable for exterior and damp environment installations.
- Universal Voltage: Operates on 120V through 277V systems.
Specifications
| Manufacturer | RAB Lighting |
| Catalog Number | CDLED2W-20W-WW927-K |
| Fixture Type | LED Cylinder Wall Mount |
| Cylinder Size | 2 Inch |
| Wattage | 20W |
| Lumen Output | 1144 Lumens |
| Color Temperature | 2700K Warm White |
| Dimming | 0-10V Dimmable |
| Voltage | 120V-277V |
| Frequency | 50/60 Hz |
| Mounting Type | Wall Mount |
| Location Rating | Wet Location |
Applications
- Architectural wall lighting
- Commercial building exteriors
- Hospitality lighting installations
- Residential modern lighting designs
- Outdoor corridors and entryways
- Accent and decorative wall illumination
Installation Tips
- Mount fixture at least 4 feet above ground level.
- Use gasket for smooth mounting surfaces in wet locations.
- Apply silicone sealant on uneven surfaces to maintain watertight installation.
- Verify proper grounding according to NEC and local electrical codes.
- Follow 0-10V dimming wiring instructions carefully for dimming systems.
Frequently Asked Questions
Is the fixture suitable for outdoor use?
Yes. The CDLED2W-20W-WW927-K is rated for wet locations and suitable for exterior wall mounting applications.
Does this fixture support dimming?
Yes. It supports 0-10V dimming with compatible control systems.
What voltage range does the fixture support?
The universal driver supports operation from 120V through 277V at 50/60Hz.
What type of lighting distribution does it provide?
This model provides direct and indirect illumination for architectural up/down lighting effects.
Documentation
Includes installation instructions, wiring diagrams, maintenance procedures, and wet location mounting guidance.
Source: RAB Lighting installation documentation.
