Product Description
BULLET20VG Bullet Flood 20/15/10W 3000/4000/5000K 120V W/ Hood &lens Verde from RAB Lighting is a field-adjustable LED bullet flood fixture with selectable wattage, selectable color temperature, and a Verde green finish. Designed for wet locations, this fixture delivers 1,147-2,095 lm with a 100,000-Hour LED lifespan and TRIAC dimming compatibility.
Product Summary
- Wattage: 20/15/10W
- Color Temperature: 3000/4000/5000K
- Voltage: 120V
- Lumens: 1,147-2,095 lm
- Finish: Verde green
- Free shipping on orders over $250
Product Benefits
- Field-adjustable light output allows the fixture to be set to 20W, 15W, or 10W to match the application.
- Selectable 3000K, 4000K, and 5000K color temperature provides flexible lighting options from one fixture.
- Suitable for wet locations with an IP65 rating for dust and water.
- TRIAC compatible dimming allows dimming as low as 10%.
Key Features
- Field Adjustable Light Output: 20W/15W/10W with factory default 20W.
- CCT Selectable: 3000K, 4000K and 5000K with factory default 4000K.
- Long LED Life: 100,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations.
- High-Efficacy LEDs: Long-life, high-efficacy, surface-mount LEDs.
- Durable Construction: Die-cast aluminum housing with glass lens.
- Heavy-Duty Mounting: Heavy-duty mounting arm with "O" ring seal and stainless steel screws.
- Green Technology: Mercury and UV free with RoHS-compliant components.
Specifications
Technical Specifications
| Product | BULLET20VG |
| Type | Constant Current |
| Driver | Constant Current, Class 1, 120V, 50/60Hz, 120V: 0.16A |
| Voltage | 120V |
| 120V Current | 0.16A |
| Input Watts | 10.6-19.6W |
| Wattage | 20/15/10W |
| Dimming Driver | TRIAC compatible dimmer with dimming as low as 10%. |
| THD | 14.95% at 120V |
| Power Factor | 98.9% at 120V |
| Surge Protection | L/N:1 kV, L/N-PE:1 kV |
| Aux Power Supply | No |
| Dim to Off | No |
Performance Specifications
| Color Temp | 3000/4000/5000K |
| Color Accuracy | 82-85 CRI |
| L70 Lifespan | 100,000 Hours |
| Lumens | 1,147-2,095 lm |
| Efficacy | 98.3-114.3 lm/W |
| NEMA Type | NEMA Beam Spread 6H x 6V |
Physical Specifications
| Color | Verde green |
| Weight | 0.8 lbs |
| Lens | Glass |
| Housing | Die-cast aluminum |
| Reflector | Polyethylene Terephthalate (PET) |
| Finish | Formulated for high durability and long-lasting color |
| Mounting | Heavy-duty mounting arm with "O" ring seal and stainless steel screws |
Compliance & Safety
| UL Listed | Suitable for wet locations |
| IESNA LM-79 & LM-80 Testing | RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80. |
| IP Rating | Ingress protection rating of IP65 for dust and water |
| Trade Agreements Act Compliant | This product is a product of Cambodia and a "designated country" end product that complies with the Trade Agreements Act |
| Cold Weather Starting | The minimum starting temperature is -40°F (-40°C) |
| Maximum Ambient Temperature | Suitable for use in up to 104°F (40°C) |
| Warranty | 5-Year, limited warranty |
Applications
- Wet location lighting applications
- Wall mounting to a weatherproof Junction Box and Cover Plate
- Ground mounting to a Mighty Post
- 120V lighting projects requiring TRIAC dimming
- Installations requiring selectable 3000K, 4000K, or 5000K color temperature
Installation Tips
- Read carefully before installing fixture and retain the instructions for future reference.
- RAB fixtures must be wired in accordance with the National Electrical Code and all applicable local codes.
- Proper grounding is required for safety.
- Make certain power is OFF before installing or maintaining fixture.
- Verify that the supply voltage is correct and connect fixture to a 120 volt, 60 Hz power source.
- For proper weatherproof seal, apply weatherproof silicone sealant around the edge of the Junction Box or Cover Plate.
- Use silicone sealant or Teflon® tape around the thread of the arm.
- All wiring connections should be capped with UL listed wire connectors.
- Aim fixture in the desired direction by loosening the Arm Screw and/or Locknut, then tighten to secure.
Frequently Asked Questions
What wattage settings are available for the BULLET20VG?
The BULLET20VG has field-adjustable light output of 20W, 15W, and 10W with factory default 20W.
What color temperatures can this fixture be set to?
This fixture is selectable between 3000K, 4000K, and 5000K with factory default 4000K.
What is the lumen output range?
The BULLET20VG delivers 1,147-2,095 lm.
Is this fixture suitable for wet locations?
Yes. The BULLET20VG is UL Listed as suitable for wet locations and has an IP65 rating for dust and water.
Can the BULLET20VG be dimmed?
Yes. It has a TRIAC compatible dimmer with dimming as low as 10%.
What voltage does this fixture use?
The BULLET20VG operates at 120V.
What is the fixture finish?
The fixture has a Verde green finish formulated for high durability and long-lasting color.
What is the LED lifespan?
The BULLET20VG has a 100,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations.
