Product Description
The WPLED26 Wall Packs 3851 Lumens WPLED 26W Bronze by RAB Lighting provides exceptional energy efficiency and durability for outdoor lighting. With a lumen output of 3,851 and a cool 5000K color temperature, this wall pack delivers reliable illumination for commercial and residential applications.
Key Features
- High lumen output of 3,851 lumens with 134.2 lm/W efficacy.
- 5000K cool white color temperature with 70 CRI for accurate color rendering.
- IP66 rated for dust and water protection, ideal for wet locations.
- 100,000-hour LED lifespan for long-term performance.
- Durable die-cast aluminum housing with superior heat sinking.
- 0-10V dimming capability down to 10% for flexible lighting control.
- RoHS-compliant, mercury, and UV-free for an environmentally friendly solution.
Specifications
- Lumen Output: 3,851 lumens
- Wattage: 26W
- Voltage: 120-277V
- Color Temperature: 5000K (Cool White)
- CRI: 70
- Lifespan: 100,000 hours (maintains 70% of initial lumens)
- IP Rating: IP66
- Ambient Temperature: -40°C to 40°C (-40°F to 104°F)
- Finish: Bronze, formulated for long-lasting durability
Installation Tips
- Ensure the fixture is mounted within 4 feet of the ground for optimal performance.
- Use the 0-10V dimming control wiring for compatible dimming systems.
- Check local electrical codes to ensure proper installation and grounding practices.
- Verify that the ambient operating temperature does not exceed 40°C (104°F).
- Use a durable mounting system to secure the fixture firmly to the wall surface.
Frequently Asked Questions
Q: What is the lumen output of this wall pack?
A: The WPLED26 provides 3,851 lumens with an efficacy of 134.2 lm/W.
Q: Is this wall pack suitable for wet locations?
A: Yes, it is UL Listed for wet locations and has an IP66 rating for dust and water protection.
Q: Does this product support dimming?
A: Yes, it features 0-10V dimming capability, allowing it to dim down to 10%.
Q: What is the lifespan of the LEDs in this fixture?
A: The LEDs have a rated lifespan of 100,000 hours, maintaining 70% of their initial brightness.
Q: Is the fixture compliant with environmental standards?
A: Yes, it is RoHS-compliant, mercury-free, and UV-free.
Q: Can this product operate in extreme temperatures?
A: Yes, it operates in temperatures ranging from -40°C to 40°C (-40°F to 104°F).
