Product Description
WFRETRO6 6" Retro Wafer from RAB Lighting offers a modern, edge-lit design that easily retrofits into existing recessed housings. With selectable wattage and color temperature, this 5CCT LED downlight provides up to 1,430 lumens, superior 90 CRI color accuracy, and reliable TRIAC/ELV dimming — ideal for residential and commercial installations.
Product Summary
- Product Type: 6" LED Retrofit Wafer Downlight
- Wattage: Field-selectable 11W / 13W / 15W
- Lumen Output: Up to 1,430 lumens
- Color Temperature: 2700K / 3000K / 3500K / 4000K / 5000K (Selectable)
- CRI: 90+
- Dimming: TRIAC/ELV down to 10%
- Voltage: 120V AC
- Lifespan: 50,000 hours (L70)
- Finish: White Smooth Trim
- Weight: 0.6 lbs
- Certifications: UL Listed, ENERGY STAR® Certified, FCC, RoHS Compliant
- Environment: Suitable for dry, damp, or wet locations
Free shipping on orders over $250
Product Benefits
- Seamless retrofit solution: Installs directly into existing 6" recessed housings — no tools required.
- Selectable wattage and CCT: Choose between three brightness levels and five color temperatures for versatile lighting design.
- High color accuracy: 90+ CRI with R9 > 50 ensures vibrant, true-to-life illumination.
- Long lifespan: Rated up to 50,000 hours for extended performance and reduced maintenance.
Key Features
- Edge-lit technology: Provides even light distribution with minimal glare.
- Adjustable settings: Field-selectable wattage (11/13/15W) and CCT (2700K–5000K) via onboard dip switch.
- Wide beam angle: 110°±10° for smooth, uniform coverage.
- TRIAC/ELV dimming: Compatible with most leading-edge and trailing-edge dimmers.
- ENERGY STAR® Certified: Meets efficiency and performance standards (ID: 3398293).
- Easy installation: E26 socket adapter and torsion spring clips included.
Enhanced Specifications
Performance Specs
| Lumen Output | 950–1,430 lm (depending on wattage/CCT) |
| Color Temperature | 2700K / 3000K / 3500K / 4000K / 5000K |
| Color Rendering Index | 90+ (R9 > 50) |
| Beam Angle | 110°±10° |
| Efficacy | Up to 106 lm/W |
| L70 Lifespan | 50,000 hours |
Electrical Specs
| Input Voltage | 120V AC, 60Hz |
| Input Current | 0.15A |
| Driver Type | Constant Current, Class 2 |
| Power Factor | 0.9 |
| THD | <20% |
| Dimming | TRIAC/ELV to 10% |
Construction & Environment
| Trim Style | Smooth, White |
| Material | Plastic + Metal with Polycarbonate Diffuser |
| Operating Temp | -13°F to 104°F (-25°C to 40°C) |
| Environment Rating | Dry, Damp, and Wet Locations |
| Air Tight | Certified per ASTM E283 |
| IC Rated | No |
Compliance & Certifications
| Certifications | UL Listed, ENERGY STAR® Certified, FCC, RoHS |
| California Title 24 | JA8 Compliant |
| CEC Status | Lawful for Sale in California |
| Warranty | 5-Year Limited Warranty |
Application Examples
- Residential retrofits replacing traditional recessed lights
- Commercial ceiling lighting with adjustable CCT flexibility
- Kitchens, living rooms, hallways, and hospitality spaces
- Bathrooms and outdoor soffit installations (wet rated)
Installation Tips
- Ensure power is off before installation and remove existing bulb and trim.
- Attach the provided E26 socket adapter to the existing housing socket.
- Set desired CCT and wattage using the dip switch on the driver box.
- Plug the fixture connector into the adapter and gently route wires into housing.
- Compress torsion springs and seat the trim flush with the ceiling.
Frequently Asked Questions
What size housings are compatible with WFRETRO6?
It fits most standard 6-inch recessed housings, including IC and non-IC rated types.
Can this fixture be dimmed?
Yes, it’s dimmable down to 10% using compatible TRIAC/ELV dimmers.
Is the color temperature adjustable?
Yes, choose from five color settings — 2700K, 3000K, 3500K, 4000K, or 5000K using the built-in selector.
Can it be installed in wet areas?
Yes, WFRETRO6 is rated for wet locations and ideal for bathrooms or covered outdoor ceilings.
Is an external driver required?
No. The driver is integrated and comes with the included E26 adapter for direct retrofit installation.
Does it qualify for energy rebates?
Yes, ENERGY STAR® certification may qualify it for regional energy efficiency rebates.
What is the lifespan and warranty?
WFRETRO6 is rated for 50,000 hours and backed by a 5-year RAB limited warranty.
