Product Description
VAN34-60FFR/480 VAN34 60/50/40W 3000/4000/5000K 480V Flat Frosted Lens Bz is a field-adjustable LED canopy/stairwell luminaire from RAB Lighting, designed for wet locations (covered ceiling) with selectable wattage, CCT, and an on/off built-in photocell for flexible performance across commercial and industrial spaces.
Product Benefits
- Dial-in performance on site: Field-selectable 60W/50W/40W and 3000K/4000K/5000K helps match output and tone to the space without changing fixtures.
- Reliable outdoor durability: IP65 dust/water protection and wet-location suitability support demanding canopy and covered exterior ceiling installations.
- Lower operating costs: High efficacy up to 147.5 lm/W with 0-10V dimming and dim-to-off capability for energy savings.
- Clean, comfortable distribution: Flat frosted polycarbonate lens helps reduce glare while delivering strong lumen packages.
Key Features
- Selectable wattage: 60W / 50W / 40W (factory default: 60W)
- Selectable CCT: 3000K / 4000K / 5000K (factory default: 4000K)
- Built-in photocell: On/off photocell with selectable switch (factory default: off)
- Dimming: 0-10V dimming, dims down to 10%; dim to off supported
- Electrical protection: Surge protection L/N: 4 kV, L/N-PE: 6 kV
- Long life: 100,000-hour LED lifespan (based on IES LM-80 results and TM-21 calculations)
- Construction: Die-cast aluminum housing, EPDM gaskets, aluminum reflector/tray, polycarbonate frosted flat lens
- Finish: Bronze (formulated for high durability and long-lasting color)
Specifications
Technical
| Driver Type | Constant Current, Class 1 |
| Input Voltage | 480V, 50/60 Hz |
| Input Watts | 40.7–61.3W |
| Input Current (480V) | 60W: 0.13A; 50W: 0.12A; 40W: 0.10A |
| Dimming | 0-10V (separate 0-10V DC dimming circuit required); dims to 10% |
| Aux Power Supply | Yes |
| Dim to Off | Yes |
| Surge Protection | L/N: 4 kV, L/N-PE: 6 kV |
| Photocell | Built-in on/off photocell with switch (factory default: off) |
Performance
| Wattage (LED) | 60W / 50W / 40W (field selectable) |
| CCT | 3000K / 4000K / 5000K (field selectable) |
| CRI | 84–86 CRI |
| Delivered Lumens | 5,671–8,588 lm |
| Efficacy | 132.5–147.5 lm/W |
| LED Lifespan | 100,000 hours |
Physical
| Finish / Color | Bronze |
| Weight | 6.0 lbs |
| Lens | Polycarbonate frosted flat lens |
| Housing | Die-cast aluminum |
| Gaskets | EPDM |
| Reflector / Tray | Aluminum |
| Cold Weather Starting | -40°F (-40°C) |
| Max Ambient | 104°F (40°C) |
Compliance & Listings
| UL Listed | Suitable for wet locations |
| IP Rating | IP65 |
| Testing | IESNA LM-79 & LM-80 (tested by an independent laboratory) |
| DLC Listed | Ultra-efficient premium; designed to meet DLC 5.1 requirements |
| DLC Product Code | S-ZZFCT4 (Stairwell and Passageway Luminaires) |
| DLC Product Code | S-3NT7VF (Fuel Pump Canopy Luminaires) |
| Green Technology | Mercury and UV free; RoHS-compliant components |
| Warranty | 5-year limited warranty (light output, driver performance, paint finish) |
Applications
- Fuel pump canopies and covered forecourt ceilings
- Stairwells, passageways, and covered exterior corridors
- Commercial building entrances and covered loading areas
- Parking structures and covered drive lanes requiring durable, wet-location rated lighting
- Projects needing 0-10V dimming and field selectable wattage/CCT for standardization across sites
Installation Tips
- Turn power OFF before installing or servicing. No user serviceable parts inside.
- Install per National Electrical Code and applicable local codes; proper grounding is required.
- For wet-location performance, ensure all gaskets are seated and all screws are tightened firmly.
- Apply weatherproof silicone sealant around the edge of the ceiling mounting box and/or junction box; silicone unused conduit entries and plugs.
- Covered ceiling ONLY for wet locations; suitable for ambient not exceeding 40°C; use 90°C supply conductors.
- 0-10V wiring: connect fixture black to LINE, white to COMMON, green to GROUND, purple to (V+) DIM, pink to (V-) DIM; cap yellow lead if present.
- Photocell switch: factory is set to OFF. If set to ON during daylight, allow up to 60 seconds for the light to turn off.
FAQ
Is the wattage adjustable on the VAN34-60FFR/480?
Yes. The fixture is field adjustable to 60W, 50W, or 40W, with the factory default set to 60W.
Can I select the color temperature?
Yes. Color temperature is field selectable between 3000K, 4000K, and 5000K, with the factory default set to 4000K.
Does this model support 0-10V dimming?
Yes. It includes dimming control wiring for 0-10V systems and requires a separate 0-10V DC dimming circuit. It dims down to 10% and supports dim to off.
Is the VAN34-60FFR/480 rated for wet locations?
Yes. It is UL Listed and suitable for wet locations when installed on a covered ceiling.
What is the IP rating?
The luminaire has an ingress protection rating of IP65 for dust and water.
Does it include a photocell?
Yes. A built-in on/off photocell is included and is selectable by switch. The factory setting is OFF.
What lumen output can I expect?
Depending on field settings, delivered lumens range from 5,671 lm to 8,588 lm.
What is the operating temperature range?
The minimum starting temperature is -40°F (-40°C) and it is suitable for use in maximum ambient temperatures up to 104°F (40°C).
What materials are used for the housing and lens?
The housing is die-cast aluminum with EPDM gaskets, and the lens is a polycarbonate frosted flat lens.
What surge protection does it include?
Surge protection is rated at L/N: 4 kV and L/N-PE: 6 kV.
