Product Description
TL20WH Trac 12 Adjustable Joiner (White) by Juno lets you connect two Trac 12™ low-voltage track sections at variable angles for clean, flexible layouts. It’s ideal for navigating corners, offsets, or height changes while maintaining a continuous, reliable electrical connection.
Product Summary
- Type: Adjustable joiner connector for Trac 12™
- Color / Finish: White
- Compatibility: Juno Trac 12™ low-voltage track system
- Adjustment: Angles left/right/up/down
- Included: Terminal block connector with cover and 4" flexible joiner cable
Shipping: Free shipping on orders over $250
Benefits
- Design flexibility: Create angles and offsets without cutting complex miters or using multiple fixed joiners.
- Clean aesthetic: Low-profile connector keeps minimalist Trac 12™ sightlines intact.
- Time-saving: Faster layout adjustments on-site versus reconfiguring sections.
- Reliable continuity: Maintains secure mechanical and electrical connection between track sections.
Key Features
- Adjustable in multiple planes: Join sections left, right, up, or down for complex runs.
- Included components: Terminal block connector with cover and 4" flexible joiner cable.
- System match: Designed for the Juno Trac 12™ miniature low-voltage track system.
- Low-profile build: Complements Trac 12’s ultra-miniature profile for a seamless look.
Specifications
Technical Specs
| Catalog Number | TL20WH |
| System | Juno Trac 12™ Low-Voltage Track |
| Function | Adjustable joiner (variable-angle connection) |
| Included Cable | 4" flexible joiner cable |
Physical Specs
| Finish | White |
| Profile Compatibility | Matches Trac 12™ ultra-miniature track profile |
Performance / System Notes
| System Voltage | 12V or 24V (system-level; per Trac 12™ transformers) |
| System Capacity | 20A conductors; typical max 240W @ 12V or 480W @ 24V per circuit (system-level) |
| Use Case | Angle, offset, vertical transitions between track sections |
Application Examples
- Retail aisles and perimeter runs requiring precise angle changes
- Gallery walls with staggered or non-linear layouts
- Residential hallways and stair transitions (up/down adjustments)
- Hospitality and boutique ceilings where clean corners are essential
Installation Tips
- Power down: De-energize the circuit before connecting the joiner.
- Prepare ends: Ensure track section ends are square, clean, and properly aligned.
- Secure connector: Attach the terminal block and cover firmly to prevent loosened contacts.
- Plan the angle: Set the desired angle before final tightening to avoid stressing the flexible cable.
- System check: Verify polarity and continuity across the connection before restoring power.
Frequently Asked Questions
Is the TL20WH compatible with all Trac 12™ sections?
Yes, it is designed specifically for Juno Trac 12™ low-voltage track sections for seamless mechanical and electrical joining.
What adjustment range does the joiner support?
It allows variable-angle connections to the left, right, up, or down, enabling both horizontal and vertical changes in direction.
Does it include everything needed to make the connection?
Yes. It comes with a terminal block connector, protective cover, and a 4-inch flexible joiner cable.
Can I use TL20WH with 12V and 24V systems?
Trac 12™ systems operate on either 12V or 24V via appropriate transformers; the adjustable joiner is suitable for use within these system configurations.
Is there a fixed 90° option if I do not need adjustability?
Yes. For fixed corners, Juno offers a right-angle joiner (e.g., TL24 series) that forms a 90-degree connection.
Do I need special tools to install the joiner?
No special tools are typically required beyond standard electrician tools. Always follow local codes and manufacturer guidance.
Will the joiner affect the track’s low-profile look?
No. The TL20WH maintains the minimalist aesthetic of the Trac 12™ system with its matching low-profile design.
Is the flexible cable replaceable?
The joiner is supplied as a complete assembly. For damaged parts, replace the joiner per manufacturer recommendations.
