NOXAC-43640WW/HL 4" AC Onyx Hl Square 4000K

Product Description

Nora NOXAC-43640WW/HL 4" AC Onyx HL Square is a driverless AC LED retrofit reflector that delivers even, glare-free illumination in a modern square aperture. This 4000K, 90+ CRI module outputs about 1000 lumens, fits most 4" housings, and ships with a medium-base socket adapter for fast upgrades.

Benefits

• Fast retrofit: Includes medium-base adapter to convert most 4" incandescent cans to high-efficacy LED.
• Clean visual comfort: Deep regressed optics and square aperture reduce glare while providing wide coverage.
• Energy-smart performance: About 1000 lumens at 14.5W with high color quality (90+ CRI).
• Code-friendly: Wet-location classification, ENERGY STAR® certification, and Title 24 JA8-2022 compliance.

Key Features

• Driverless AC LED design (no remote driver to mount)
• Square reflector with crisp die-cast edges; white finish
• 110° wide-flood distribution for uniform ambient light
• Triac or ELV dimming for smooth control with common wall dimmers
• Spring-blade mounting compatible with most 4" IC / Non-IC housings
• 5-year limited warranty

Specifications

Technical Specs

Input Voltage	120V AC
Wattage	14.5W nominal
Lumen Output (4000K)	~1022 lm delivered
CCT / CRI	4000K / 90+ CRI (series also 2700K, 3000K)
Dimming	Triac (leading edge) or ELV (trailing edge)
Beam Spread	110° wide flood
Operating Temp	0–30 °C

Physical Specs

Construction	One-piece die-cast aluminum reflector; UTM thermal management
Finish	White (WW/HL)
Mounting	Two steel spring blades for most 4" housings; medium-base (E26) adapter included (NRA-211SM)
Optional Adapter	GU24 socket adapter (NRA-212SM) for GU24 housings

Compliance & Safety

Listings	cETLus Wet Location; ENERGY STAR®; FCC
Air-Tight	Meets ASTM-E283
Title 24	Certified to JA8-2022 high-efficacy requirements
Warranty	5-Year Limited

Compatible Housings (Selection)

Fire Box	NFBIC-4LMRATA; NFBIC-427LMRATA; NFBIC-4INCATA
New Construction	NHIC-4LMRAT; NHIC-4LMRAT/277; NHICCP-4LMRAT; NHIC-427LMRAT; NSIC-401QAT; NS-401QAT; NHIC-4G24AT
Remodel	NHRIC-4LMRAT; NHRIC-427LMRAT; NSR-404QAT; NSRIC-404QAT

Application Examples

• Residential kitchens, baths, hallways, and living areas
• Light commercial corridors and lobbies needing glare-controlled ambient light
• Shower and covered outdoor locations requiring wet-location classification

Installation Tips

• Power off the circuit. Remove existing lamp/trim and screw in the included E26 adapter.
• Connect the module lead, compress spring blades, and seat the square reflector flush.
• For GU24 cans, use the optional NRA-212SM adapter.
• Use compatible Triac or ELV dimmers; see manufacturer dimmer list for best low-level performance.
• Operate within 0–30 °C; ensure housing is 4" class and air-tight per local code.

Frequently Asked Questions

Is a separate driver required?

No. This is a driverless AC LED module that connects directly to 120V via the included E26 adapter.

How bright is the 4000K model?

The 4000K version delivers approximately 1022 lumens with a wide 110° beam.

Will it fit my existing 4" can?

Yes. It’s designed for most 4" IC or Non-IC housings and includes spring blades and a medium-base adapter.

Is it dimmable?

Yes, with Triac (leading edge) or ELV (trailing edge) wall dimmers.

Is it wet-location rated?

Yes. It’s cETLus classified for wet locations, and it’s also ENERGY STAR® and Title 24 JA8-2022 compliant.

What finish is supplied with this part number?

WW/HL denotes a white finish square reflector.

Does it include a GU24 adapter?

It ships with the E26 adapter. A GU24 adapter (NRA-212SM) is available separately for GU24 housings.

What is the operating temperature range?

0–30 °C ambient.
