Product Description
The NLCBC2-55130WW/10 by Nora Lighting is a high-performance 5" LED retrofit reflector from the Cobalt Click series. Delivering up to 1000 lumens at a warm 3000K color temperature with 90+ CRI, this energy-efficient 12W downlight installs easily into existing housings and is compatible with Triac, ELV, and 0-10V dimming systems. Designed with Nora's patented “Click” trim system, it offers premium field flexibility and sleek aesthetics.
| Brand | Nora Lighting |
| Model | NLCBC2-55130WW/10 |
| Wattage | 12W |
| Lumens | 1000 lm |
| Color Temperature | 3000K (Warm White) |
| Finish | White Baffle / White Flange |
| Free Shipping | Free shipping on orders over $250 |
Product Benefits
- Generates up to 1000 lumens at only 12W for efficient illumination
- 90+ CRI provides vivid, accurate color rendering for premium spaces
- Includes medium base adapter for seamless retrofitting into 5" recessed housings
- Patented Click system makes trim swaps fast and secure
Key Features
- Beam Spread: 101° wide flood for uniform ambient lighting
- Dimming: Triac, ELV, or 0-10V compatible (LE4 driver required for 0-10V)
- Mounting: Secure torsion spring blades for tool-free installation
- Certifications: ENERGY STAR, Title 24 JA8-2022, Wet Location listed
- Lifetime: Rated for 50,000 hours at L70
Specifications
Technical Specs
| Input Voltage | 120V (standard) / 120V-277V with specified driver |
| Wattage | 12W |
| Dimming | Triac / ELV / 0-10V |
| Operating Temperature | 0°C to 35°C |
Performance Specs
| Lumens | 965 lm |
| Efficacy | 85 lm/W |
| Color Temperature | 3000K |
| CRI | 90+ |
Physical Specs
| Reflector Trim Diameter | 6-1/4" |
| Height | 4-5/16" |
Application Examples
- Residential kitchens, living rooms, and bathrooms
- Hospitality lighting in hotels or restaurants
- Retail ceiling retrofits and upgrades
- Multifamily housing units and corridors
Installation Tips
- Use medium base adapter (included) or GU24 socket adapter (sold separately)
- Compatible with most 5" IC and Non-IC housings
- Choose LE4 driver if 0-10V dimming is required
- Optional oversize ring helps conceal large ceiling openings
Frequently Asked Questions
Q: Is this fixture ENERGY STAR certified?
A: Yes, it is ENERGY STAR rated and Title 24 JA8-2022 compliant (excluding black, bronze, and copper finishes).
Q: What is the beam angle of this downlight?
A: It delivers a 101° wide flood beam for even distribution.
Q: Can this be installed in a wet location?
A: Yes, it is cULus classified for wet locations.
Q: What finishes are available?
A: The 551 model is available in finishes including White, Matte Powder White, Haze/White, and more.
Q: What dimmers are supported?
A: Triac and ELV dimming are standard; 0-10V dimming requires LE4 driver.
Q: Can the trim be swapped?
A: Yes, the patented Click system allows field changeable trims without tools.
