Product Description
NIO-4RNDCCDXMPW 4" Iolite LED Round Reflector 800LM / 14W Comfort Dim Matte Powder delivers versatile illumination with Nora’s Comfort Dim technology, which gradually warms from 3100K to 2000K as the light dims. Built with a deep regressed cone reflector for glare control and high visual comfort, this ENERGY STAR certified downlight is designed for use with dedicated Iolite housings in residential, retail, or hospitality applications.
- Lumen Output: 800 lumens
- Wattage: 14W
- Color Temperature: Comfort Dim 3100K → 2000K
- CRI: 90+
- Finish: Matte Powder White
- Certification: ENERGY STAR, Title 24 JA8-2022, cULus Wet Location
- Shipping: Free shipping on orders over $250
Product Benefits
- Warm dimming technology recreates the glow of incandescent light as it dims.
- Deep regressed cone design for superior glare control and visual comfort.
- Field-changeable optics allow quick adjustment between spot, narrow flood, and flood distributions.
- ENERGY STAR certified for efficiency and Title 24 JA8-2022 compliance for California projects.
Key Features
- Construction: Die-cast aluminum trim with integrated heat sink for thermal management.
- Optics: Spot, narrow flood, and flood optics included; optional frosted and premium TIR optics available.
- Dimming: Comfort Dim gradual curve from 3100K to 2000K, dimming range specified by housing.
- Lifetime: Rated for 50,000 hours at L70.
- Mounting: Friction blades secure reflector to dedicated Iolite housing.
- Listings: cULus wet location listed, ENERGY STAR, RoHS compliant.
Specifications
| Performance Specs | |
|---|---|
| Catalog Number | NIO-4RNDCCDXMPW |
| Lumen Output | 800 lm |
| Wattage | 14W |
| Color Temperature | Comfort Dim 3100K → 2000K |
| CRI | 90+ |
| Beam Options | Spot, Narrow Flood, Flood (field changeable) |
| Input Voltage | 120V (via housing) |
| Finish | Matte Powder White |
| Life Expectancy | 50,000 hours @ L70 |
| Certifications | ENERGY STAR, Title 24 JA8-2022, cULus Wet Location |
Application Examples
- Residential living and dining rooms where warm dimming enhances ambiance.
- Hospitality lighting in restaurants, hotels, and lounges.
- Retail displays requiring flexible optics and glare-free presentation.
- Bathroom and shower lighting with wet location compliance.
Installation Tips
- Requires a dedicated Iolite housing such as NHIOICD-48 (new construction) or NHRIOIC-48 (remodel).
- Select proper housing based on project type (ICAT, Chicago Plenum, or Remodel).
- Use included optics for tailored beam spreads; optional hex louver and decorative collars available.
- Ensure dimmer compatibility with Comfort Dim technology for smooth performance.
FAQ
Q: What is Comfort Dim?
A: Comfort Dim is Nora’s warm dimming technology that transitions color temperature from 3100K down to 2000K as the fixture dims, simulating incandescent lighting.
Q: Does this fixture include optics?
A: Yes, it includes spot, narrow flood, and flood optics that are field-changeable.
Q: Can this fixture be used in wet locations?
A: Yes, it is cULus listed for wet locations, suitable for bathrooms and covered outdoor areas.
Q: Is housing required?
A: Yes, it requires a dedicated Nora Iolite new construction or remodel housing.
Q: What finishes are available?
A: Available in Matte Powder White, Black, Bronze, Haze, Champagne, and other designer finishes.
Q: What is the rated lifetime?
A: It is rated for 50,000 hours at L70 performance.
