Product Description
G2R5940120W Downlights 436 Lumens Dl Gimbal 2" Round 5W 90CRI 4000K 120V by RAB Lighting is a high-performance recessed LED gimbal downlight, offering flexible aiming with a 360° rotation and 30° tilt. Ideal for accent lighting in residential or commercial spaces, this compact 2" fixture delivers brilliant, flicker-free illumination with high color accuracy and energy efficiency, all in a sleek matte white finish.
G2R5940120W 2" Round Gimbal Downlight
Wattage: 5W
Color Temperature: 4000K (Neutral)
Lumens: 436 lm
CRI: 90+
Voltage: 120V
Dimming: TRIAC down to 5%
Mounting: Spring clip installation
Finish: Matte White
Free shipping on orders over $250
Product Benefits
- High-CRI 90+ lighting delivers accurate color rendering for architectural or retail settings
- Adjustable gimbal head with 360° rotation and 30° tilt for precise light placement
- ENERGY STAR® certified for efficiency and rebate eligibility
- IC-rated and air-tight, suitable for new construction or retrofit installs
Key Features
- Output: 436 lumens at 5W
- Efficacy: 80 lm/W
- Color Temperature: 4000K Neutral
- Adjustability: 30° tilt and full 360° rotation
- Beam Angle: 38° for focused accent lighting
- Driver: Remote, plenum-rated with 12AWG/14AWG compatibility
- Dimming: TRIAC compatible (5% min dim level)
- Compliance: UL Listed, Title 24, NEC Closet Rated, Energy Star Certified
- Warranty: 5-Year No-Compromise Warranty
Specifications
| Technical Specs | |
|---|---|
| Input Voltage | 120V, 60 Hz |
| Driver Type | Constant Current, TRIAC dimming |
| Power Factor | ≥ 0.9 |
| Operating Temp | -30°C to 35°C (-22°F to 95°F) |
| Physical Specs | |
|---|---|
| Construction | Die-cast aluminum |
| Finish | Matte White |
| Trim Style | Smooth |
| Mounting | Spring-loaded retention clips |
| Lens | Diffuse polystyrene |
| IC Rating | Yes – suitable for direct contact with insulation |
| Performance Specs | |
|---|---|
| Lumen Output | 436 lumens |
| Color Temperature | 4000K (Neutral) |
| CRI | 90+ |
| Lifespan | 50,000 hours (L70) |
| Wattage Equivalent | 40W Incandescent |
Application Examples
- Accent lighting for art, shelving, or architectural features
- Hallways, closets, and tight ceiling spaces
- Hospitality and retail environments
- Residential kitchen and bath remodels
Installation Tips
- Use included template to cut the correct ceiling hole size
- Driver box includes knockouts for easy wiring; fits in plenum space
- Secure fixture with spring retention clips; no housing needed
- Connect power with wire nuts (black to black, white to white, ground to ground)
- Confirm dimmer compatibility for optimal TRIAC dimming
Frequently Asked Questions
What size opening is required?
This 2" round fixture installs into a 2 ¾" diameter ceiling opening using the included template.
Does it include a driver?
Yes, it comes with a remote plenum-rated driver box and connector cable.
Is this fixture dimmable?
Yes, it is compatible with most TRIAC dimmers and dims as low as 5%.
Can it be used in closets?
Yes, it complies with NEC Sec. 410.16 for closet lighting installations.
Is this fixture air-tight?
Yes, certified Air Tight per ASTM E283.
Is the light color accurate?
Absolutely. It has a CRI rating of 90+ and R9 ≥ 50 for rich color fidelity.
Do I need a housing can or J-box?
No, this unit installs directly into drywall ceilings—ideal for retrofit or new construction.
Is this fixture Energy Star certified?
Yes, it meets Energy Star Version 2.2 standards.
Can this be used outdoors?
It is rated for wet locations and suitable for covered exterior applications.
