Product Description
BULLET12VG — Bullet Flood 12W/9W/6W Field Adjustable LED CCT Selectable 3000K/4000K/5000K with Hood & Lens Verde Green from RAB Lighting is a compact, durable LED floodlight designed for high-performance outdoor lighting. Featuring field-adjustable wattage and selectable color temperatures, this versatile fixture delivers efficient illumination with a distinctive verde green finish, making it ideal for landscape, security, and architectural lighting applications.
Product Summary
- Wattage: 12W / 9W / 6W selectable
- Lumens: 636 – 1324 lm
- Color Temperature: 3000K / 4000K / 5000K selectable
- Voltage: 120V
- CRI: 82–85 CRI
- Beam Spread: NEMA 6H x 6V
- Rating: IP65 Wet Location Rated
- Lifespan: 100000 hours
- Finish: Verde Green
- Warranty: 5-Year Limited
- Shipping: Free shipping on orders over $250
Product Benefits
- Field-adjustable wattage and selectable CCT allow customization for various lighting environments and applications.
- Durable construction with weather-resistant materials ensures long-lasting outdoor performance.
- High lumen output combined with efficient LED technology reduces energy consumption.
- Long 100000-hour lifespan minimizes maintenance and replacement costs.
Key Features
- Adjustable Output: Selectable 12W, 9W, or 6W for flexible lighting levels.
- CCT Selectable: 3000K, 4000K, or 5000K color temperature options.
- TRIAC Dimming: Dims down to 10% with compatible dimmers.
- IP65 Rated: Protection against dust and water for outdoor environments.
- Robust Housing: Die-cast aluminum body with glass lens.
- Wide Operating Range: -40°F to 104°F for reliable performance.
- High Efficiency: Up to 116.4 lm/W efficacy.
- Secure Mounting: Heavy-duty mounting arm with O-ring seal and stainless steel screws.
Specifications
Technical Specifications
| Wattage | 12W / 9W / 6W |
| Voltage | 120V |
| Input Watts | 5.7W – 12.3W |
| Current | 0.10A |
| Power Factor | 99% |
| THD | 14.53% |
| Surge Protection | 1kV |
Performance Specifications
| Lumens | 636 – 1324 lm |
| Efficacy | 100.2 – 116.4 lm/W |
| CRI | 82 – 85 |
| CCT | 3000K / 4000K / 5000K |
| Lifespan | 100000 hours |
| Beam Spread | NEMA 6H x 6V |
Physical & Construction
| Housing | Die-cast aluminum |
| Lens | Glass |
| Reflector | PET |
| Finish | Verde Green |
| Weight | 0.8 lbs |
| Operating Temp | -40°F to 104°F |
Compliance & Safety
| Listings | UL Listed for wet locations |
| IP Rating | IP65 |
| Testing | IESNA LM-79 & LM-80 |
| Compliance | Trade Agreements Act Compliant |
| Environmental | RoHS compliant, mercury & UV free |
Applications
- Landscape and garden lighting
- Security and perimeter lighting
- Architectural accent illumination
- Sign and display lighting
- Residential and commercial outdoor installations
Installation Tips
- Mount securely using the included heavy-duty arm and hardware.
- Ensure proper sealing with the O-ring to maintain IP65 protection.
- Adjust wattage and color temperature prior to final installation.
- Install within rated temperature limits for best performance.
- Use compatible TRIAC dimmers for smooth dimming control.
FAQ
Can I adjust the wattage?
Yes, the fixture allows selection between 12W, 9W, and 6W.
What color temperatures are available?
You can select between 3000K, 4000K, and 5000K.
Is this light dimmable?
Yes, it supports TRIAC dimming down to 10%.
Is it suitable for outdoor use?
Yes, it is UL listed for wet locations and rated IP65.
What is the lifespan of this light?
The LED is rated for up to 100000 hours.
What is the beam spread?
It features a NEMA 6H x 6V beam spread.
What materials are used in construction?
It includes a die-cast aluminum housing, glass lens, and PET reflector.
Can it operate in extreme temperatures?
Yes, it operates from -40°F to 104°F.
